Cisco CBS250-48T-4G 48-Port Gigabit Smart Managed Switch 4x 1G SFP

L2/L3 NEW

USD $229.99

Condition : Excellent - Refurbished

Free Shipping

{{variant_type_name}} :
eBay
SKU: CBS250-48T-4G-NA, CBS250-48T-4G This site contains affiliate links for which we may be compensated Computers/Tablets & Networking / Enterprise Networking, Servers / Switches & Hubs / Network Switches

Notify me when the price drops

We will email you if we find a lower price on this product!

Target price (USD) $
Cisco CBS250-48T-4G 48-Port Gigabit Smart Managed Switch 4x 1G SFP L2/L3 New

The Cisco CBS250-48T-4G (NA) is a 48-port Gigabit Ethernet Smart Managed Switch with 4x 1G SFP fiber uplinks, built for small and mid-size business networks, branch offices, and access-layer deployments. Part of the Cisco Business 250 Series, it delivers 104 Gbps switching capacity, 77.38 Mpps forwarding, Layer 2 switching with Layer 3 static routing for inter-VLAN traffic, plus VLAN segmentation and QoS for voice and video — all configurable through a simple web GUI or the Cisco Business Dashboard. This is a non-PoE model — for PoE+ output, see the CBS250-48P-4G or CBS250-48PP-4G variants.

Cisco CBS250-48T-4G - Key Features & Benefits
  • 48 Gigabit RJ-45 + 4x 1G SFP Uplinks: 48x 10/100/1000BASE-T access ports plus 4x 1G SFP fiber uplinks for backbone aggregation, IDF-to-MDF runs, and multi-switch deployments.
  • Smart Managed with Layer 3 Static Routing: 104 Gbps switching capacity and 77.38 Mpps forwarding (wire-speed, non-blocking); supports up to 255 active VLANs, STP/RSTP/MSTP, LACP link aggregation, and IPv4/IPv6 static routing with up to 32 static routes and 16 IP interfaces for inter-VLAN traffic.
  • QoS for Voice, Video & Data: 8 hardware queues with Auto Voice VLAN, 802.1p and DSCP traffic prioritization, plus jumbo frame support — suited to small-business VoIP, video conferencing, and surveillance traffic.
  • Network Security at the Access Layer: 802.1X port authentication, RADIUS, port security, up to 512 ACLs, storm control, and DoS attack prevention protect against rogue devices and common LAN attacks.
  • Easy Management — Web GUI, SNMP, Cisco Business Dashboard: Configure via HTTPS web interface, SNMP v1/v2c/v3, or SSH CLI; deploy and monitor multiple switches centrally with the free Cisco Business Dashboard and mobile app.
Cisco CBS250-48T-4G - Technical Specifications
  • Brand • Series: Cisco • Business 250 Series Smart Switches
  • Part Number: CBS250-48T-4G-NA
  • Ports: 48x 10/100/1000BASE-T RJ-45 • 4x 1G SFP uplinks
  • PoE: Not supported (non-PoE model)
  • Switching Capacity • Forwarding Rate: 104 Gbps • 77.38 Mpps (wire-speed, non-blocking)
  • MAC Address Table • Packet Buffer: 8K entries • 3 MB
  • VLANs • Active VLANs: 802.1Q tag-based • up to 255 simultaneously
  • Link Aggregation: IEEE 802.3ad LACP • up to 4 LAGs • up to 8 ports per LAG
  • Layer 2: STP/RSTP/MSTP, Jumbo Frames, IGMPv1/2/3 & MLDv1/2 Snooping, Loopback Detection
  • Layer 3: IPv4 & IPv6 static routing • 32 static routes • 16 IP interfaces (no dynamic routing)
  • Security: 802.1X, RADIUS, Port Security, ACLs (up to 512 rules), Storm Control, DoS Prevention, SSH, SSL/HTTPS
  • QoS: 8 hardware queues, Auto Voice VLAN, 802.1p CoS, DSCP, Strict Priority & WRR scheduling
  • Management: Web GUI (HTTP/HTTPS), SNMP v1/v2c/v3, SSH CLI, Cisco Business Dashboard, Cisco Business mobile app
  • Stacking: No physical stacking • centralized management of multiple units via Cisco Business Dashboard
  • Form Factor • Power Input: 1U Rackmount • 100–240V AC, 50/60 Hz internal universal supply
  • Max Power Consumption: ~110W
  • Operating Temperature: 32°F to 113°F (0°C to 45°C)
  • Dimensions (W x D x H): 17.5" x 10.1" x 1.73" (445 x 257 x 44 mm)
  • Standards: IEEE 802.3, 802.3u, 802.3ab, 802.3ad, 802.3az, 802.1D, 802.1Q, 802.1w, 802.1s, 802.1X
  • Condition: New
Cisco CBS250-48T-4G - Frequently Asked Questions (FAQ)
  • Does this switch support PoE or PoE+?
    No — the CBS250-48T-4G is a non-PoE model. To power IP phones, APs, and cameras over the same cable, use the CBS250-48P-4G (370W PoE+ budget) or CBS250-48PP-4G (195W partial PoE+) instead.
  • What is the difference between the CBS250-48T-4G and the CBS250-48T-4X?
    Both are 48-port Gigabit smart switches with no PoE. The -4G has 4x 1G SFP uplinks; the -4X has 4x 10G SFP+ uplinks with higher overall switching capacity (176 Gbps vs 104 Gbps) for higher-bandwidth backbones.
  • Does it support full Layer 3 routing or stacking?
    It supports IPv4 and IPv6 static routing only (up to 32 routes, 16 IP interfaces) for inter-VLAN traffic — no dynamic routing protocols such as OSPF, RIP, or BGP. There is no physical stacking, but multiple switches can be deployed and monitored centrally through the Cisco Business Dashboard.
ATHQ is 100% US owned and operated, ensuring same-day shipping from our USA location. We pride ourselves in providing premium quality products at low prices! We always provide Satisfaction Guarantee to our customers. Please contact us if any issue arises.
